Use the right design rules

Ensure that your design rules apply to both blind and buried holes to avoid any problems during manufacturing or testing, such as short circuits or poor solder joints due to incorrect soldering or excessive paste residue around through holes that have been soldered in a non-optimal manner.


Use blind or buried holes only for signal routing

Blind burials are usually used for signal routing; However, they can also be used for power lines, reference layers, ground layers, etc. If you are using blind or buried holes for power or grounding, be sure to follow the correct impedance guidelines for each layer to keep the appropriate current flowing through these layer planes (i.e., use wide pads on the top layer to minimize inductance).


Avoid blind holes and buried holes in areas of high thermal expansion

The coefficient of thermal expansion varies from material to material, and one layer on a multilayer (MLB) is different from another. Therefore, it is important to avoid placing blind and buried holes in areas with high thermal expansion or high temperature cycles, as these conditions may cause unnecessary stress in these areas that can lead to cracking or other problems later in the life of the product.


Avoid critical path

It is important not to place too many blind or buried holes in the critical path on the board. This will increase the possibility of interlayer short circuit and significantly reduce the yield.


Minimum length

The longer the length of the blind or buried holes, the higher the risk of damage from interlayer short circuits or from poor wiring during assembly or excessive trimming of the copper thread due to lack of clearance. Always minimize the length of blind and buried holes to reduce this risk.


Final judgment

HDI blind hole PCBS are becoming the new standard in the electronics industry and there is no shortage of information if you want to make one. However, many guidelines ignore the blind and buried holes required in most designs, which can easily lead to poor board design. We hope our guide has been helpful to you and brings your HDI PCB project closer to completion. If you are interested in learning more about HDI blind hole PCBS and the different types of through-holes, please check out Towers Electronics.
