Kingford

PCB process production

Kingford has its own 5000 square meters workshop, and is equipped with laser marking machine board, laser cutting machine,

CNC drilling machine, PCB laminating machine, PCB silk screen printing, PCB CNC machine tool, automatic PCB tester,

PCB two-dimensional inspection, PCB flying Needle tester and other equipment, is committed to building a first-class

production line, escorting the price of PCB quality.

Drilling rig

PTH equipment

Electroplate

Laser ldi

Solder resist

Inkjet machine

Test machine

Cutting machine

Gong machine

New imported drilling rig, high load, high precision ball screw, high stability during operation.

Guaranteeing the hole-copper bonding rate can reduce the risk of the hole being free of copper.

The uniformity of copper plating is over 99%, ensuring the quality of copper plating.

High accuracy of alignment and imaging, higher parallel depth of field.

Prevents non-soldered points from being stained with solder, which is convenient for SMD packaging.

Digital printing, multi-head technology, and motion control can make the surface text clearer and mo...

100% test functional open and short circuit to ensure that each piece is a good test product.

The external dimension has higher precision, the cut surface is smooth, and there is no burr.

Adopt double table independent motion design, accurate positioning, strong operation flexibility, an...

Kingford

Kingford PCBA good quality comes from good equipment

We have newly imported Yamaha high-end equipment, which can realize standardized production from solder paste printing,

SPI testing, reflow soldering and other links, which can improve production efficiency. Warehousing - Express" standardized process.

Ensure accurate quantity of incoming materials, ensure correct post-production, and deliver on time.

Detailed cleaning of each PCB to ensure that the PCB is free of impurities, dust, etc.

The equipped solder paste printing machine can process the PCB size up to 50*50mm, the maximum is 40...

Kingford uses Stech automatic solder paste machine for automatic detection. The minimum detection co...

With newly imported Yamaha solder paste printing, the minimum size that can be mounted is 01005, and...

Kingford is equipped with ten temperature zones for nitrogen reflow soldering, 10 temperature zones ...

Kingford conducts product quality inspection before the batch starts, in order to avoid large batche...

Kingford has 2 production lines, equipped with a DIP workshop of 8 million square meters, with a dai...

Kingford has passed the ISO9001 quality management system certification, which can guarantee product...

In order to ensure product quality, we can provide three-proof coating services, which can reduce mo...

kingford cooperates with express companies such as DHL, FedEx, UPS, EMS, TNT, etc. in pursuit of the...

Point material storage

Loader

Solder Paste Printing

SPI

Surface mount

Nitrogen reflow soldering

First article inspection

DIP

QA detection

Three anti-coating

Package
