4-layer sphygmomanometer PCB design

sphygmomanometer PCB design

Name: 4-layer sphygmomanometer PCB design

Designable layers: 1-32 layers

Minimum line width and line spacing: 3mil

Minimum laser aperture: 4mil

Minimum mechanical aperture: 8mil

Copper foil thickness: 18-175цm (standard: 18цm35цm70цm)

Peel strength: 1.25N/mm

Minimum punching hole diameter: single side: 0.9mm/35mil

Minimum hole diameter: 0.25mm/10mil

Aperture tolerance: ≤φ0.8mm±0.05mm

Hole tolerance: ±0.05mm

Hole wall copper thickness: double-sided/multi-layer: ≥2um/0.8mil

Hole resistance: double-sided/multi-layer: ≤300цΩ

Minimum line width: 0.127mm/5mil

Minimum pitch: 0.127mm/5mil

Screen printing color: black, white, red, green, etc.

Surface treatment: lead/lead-free tin spray, ENIG, silver, OSP

Service: Provide OEM service

Certificate: ISO9001.ROSH.UL

Product Details Data Sheet

1. Product parameters of electronic sphygmomanometer program

Measurement method: oscillometric method

Implementation method: boost measurement

Pressure measurement range: 0~ to 299mmHg (0~ to 39.9kPa)

Pressure accuracy: within ±3mmHg (±0.4kPa)

Pressure unit: mmHg/kPa

Pulse range: 40~200 beats/min

Pulse Accuracy: Accuracy is ±5%

Display mode: LCD digital display

Power supply: built-in lithium battery (can be customized to develop dry battery models)

History: 100 groups

2. Introduction of electronic sphygmomanometer solution chip

High-performance 32-bit RISC processor

The CPU can use a proprietary C code compiler

120MHz operation operation

16kB high-performance cache

1/2/4 data line (SFC) SPI flash controller compatible

64 vectorized interrupts

4 levels of interrupt priority

3. Features of electronic sphygmomanometer

Electronic sphygmomanometer solution, accurate measurement, real voice broadcast results,

Large screen, clearer display, algorithm after extensive clinical testing, more stable.

One-key measurement, easy to use, good stability, environmentally friendly materials, use with confidence

Built-in background music, more soothing when measuring blood pressure.

Support unit switching

1 minute no operation automatic shutdown

Low voltage warning

Support malfunction detection

Name: 4-layer sphygmomanometer PCB design

Designable layers: 1-32 layers

Minimum line width and line spacing: 3mil

Minimum laser aperture: 4mil

Minimum mechanical aperture: 8mil

Copper foil thickness: 18-175цm (standard: 18цm35цm70цm)

Peel strength: 1.25N/mm

Minimum punching hole diameter: single side: 0.9mm/35mil

Minimum hole diameter: 0.25mm/10mil

Aperture tolerance: ≤φ0.8mm±0.05mm

Hole tolerance: ±0.05mm

Hole wall copper thickness: double-sided/multi-layer: ≥2um/0.8mil

Hole resistance: double-sided/multi-layer: ≤300цΩ

Minimum line width: 0.127mm/5mil

Minimum pitch: 0.127mm/5mil

Screen printing color: black, white, red, green, etc.

Surface treatment: lead/lead-free tin spray, ENIG, silver, OSP

Service: Provide OEM service

Certificate: ISO9001.ROSH.UL

Just upload Gerber files, BOM files and design files, and the KINGFORD team will provide a complete quotation within 24h.
