- PCB Design Capabilities
PCB Design&Layout Capabilities | |||
Min.trace width: | 2.5mil | Min.trace spacing | 2.5mil |
Min.Vias: | 6mil(4mil laser drilling) | Max.layer | 48L |
Min.BGA spacing | 0.35mm | Max.BGA Pin | 3600pin |
Max.high-speed signal | 40 GBPS | Fastest delivery time | 6 Hours/ Item |
HDI Highest layer | 22 L | HDI Highest layer | 14 L any layer HDI |
PCB Design&Layout lead time | |||
Number of pins on the board | 0-1000 | Design lead time (working days) | 3-5 days |
2000-3000 | 5-8 days | ||
4000-5000 | 8-12 days | ||
6000-7000 | 12-15 days | ||
8000-9000 | 15-18 days | ||
10000-12000 | 18-20 days | ||
13000-15000 | 20-22 days | ||
16000-18000 | 22-25 days | ||
18000-20000 | 25-30 days | ||
Ultimate delivery capacity | 10000Pin/7 days | ||
PS: The above delivery date is the regular delivery date, and the accurate design delivery date needs to be comprehensively evaluated according to the number of components, difficulty, layers and other factors of the circuit board! |
Kingford
Why choose us?
Kingford
Industries we serve
Kingford
Impedance Control PCB Design FAQ
If the impedances do not match, the maximum power will not be delivered.
Impedance voltage can be reduced by reducing the number of turns in the low voltage winding and increasing the core window height.
Impedance affects how signals travel through the board, how power is transferred between components, and how signals penetrate into unwanted areas of the PCB.
What is Controlled Impedance? Controlled impedance is the characteristic impedance of the transmission line formed by the PCB traces and their associated reference planes.
Just upload Gerber files, BOM files and design files, and the KINGFORD team will provide a complete quotation within 24h.
