PCB board copy board is how to come step by step

PCB copying board, currently in the industry is often called circuit board copying board, circuit board cloning, circuit board copying, PCB cloning, PCB reverse design or PCB reverse research and development, on the definition of PCB copying board, industry and academia have a variety of statements, but are not complete, if you want to give the PCB copying board next accurate definition, We can learn from the domestic authoritative PCB board copying laboratory: PCB board copying, that is, on the premise that there are physical electronic products and circuit boards, reverse analysis of circuit boards is carried out by using reverse R&D technology, and PCB files, bill of materials (BOM) files, schematic files and other technical documents of original products as well as PCB silkscreen production documents are carried out. 1: 1, and then use these technical documents and production documents for PCB board making, component welding, fly needle testing, circuit board debugging, and complete the complete copy of the original circuit board template. Because electronic products are composed of various types of circuit board core control part of the work, therefore, using PCB copy board such a process, can complete the extraction of a full set of technical data of any electronic products and product imitation and cloning.

Many people misunderstand the concept of PCB copying board. In fact, with the continuous development and deepening of the copying board industry, today's concept of PCB copying board has been extended in a wider range. It is no longer limited to the simple copying and cloning of circuit boards, but also involves the secondary development of products and the research and development of new products. For example, through the analysis of existing product technical documents, the understanding and discussion of design ideas, structural features and process technology, it can provide feasibility analysis and competitive reference for the research and development design of new products, assist research and development design units to timely follow up the latest technological development trend, timely adjust and improve product design schemes, and develop the most competitive new products in the market. At the same time, the process of PCB board copying can realize the rapid update, upgrade and secondary development of various types of electronic products through the extraction and partial modification of technical data files. According to the extracted file drawing and schematic diagram of PCB board copying, professional designers can also optimize the design and change the PCB board according to the wishes of customers. On this basis, new functions can be added to the product or functional features can be redesigned. In this way, the product with new functions will appear in the fastest speed and new attitude. It not only owns its own intellectual property rights, but also wins the opportunity in the market, bringing double benefits to customers.

At present, when many PCB copying board design service enterprises are trying to survive and pursue profits in the market, a few enterprises have begun to establish their position at a higher level and become the leader in the industry. Among them, the most successful, the largest, the strongest technical strength, and the most comprehensive service are Longren PCB Studio, Century Core and other civil reverse R&D technical teams that first emerged in China. Their success proves that PCB boards have a lot of power. This energy is not only for the board design service enterprises, but also for the entire electronic product market and information technology industry, because objectively they promote the technical capability of Chinese enterprises, and completely break the technical barriers.

Development history

The concept of PCB copying board was originally born in the 1980s when reverse engineering began to rise in domestic academia. It was a new concept proposed by Longren PCB Studio, the first reverse engineering technology research team in China at that time. After nearly 30 years of development, PCB copying board has become a global industry serving the development of global electronics industry and domestic core technology research, domestic and foreign all kinds of copying board companies have blossomed everywhere. In recent years, the development of this industry and its various sensational in the field of science and technology, more and more people began to pay attention to it, and more enterprises through their services into the era of technology dare to compete with the international big enterprises. Especially in Jiangsu, Zhejiang and Guangdong regions of China, PCB copying board is more popular, and there are a number of specialized in PCB copying board technology research of authoritative laboratories, such as Longren PCB Studio, Century Core technology, Core Valley and so on.
