2OZ oz aluminum circuit board

2OZ oz aluminum circuit board

Name: 2OZ oz aluminum base circuit board

Number of layers: single-sided aluminum substrate

Plate thickness: 2.0MM

Copper thickness: 2OZ oz

Color: white text

Surface treatment: spray tin process

Breakdown voltage: 3000V

Thermal conductivity - thermal conductivity (W/m-k): 2.0

Application field: LED lighting

Product Details Data Sheet

The thicker the copper, the greater the loaded current load, and the transmission current and heat will greatly increase. For example, the 2OZ copper thickness will be significantly higher than the heat and current of the 1OZ Anshita thick circuit board, which greatly improves the circuit performance and ensures the product of the product. Quality, which increases the life of electrical appliances.


Name: 2OZ oz aluminum base circuit board

Number of layers: single-sided aluminum substrate

Plate thickness: 2.0MM

Copper thickness: 2OZ oz

Color: white text

Surface treatment: spray tin process

Breakdown voltage: 3000V

Thermal conductivity - thermal conductivity (W/m-k): 2.0

Application field: LED lighting
