Rigid-Flex PCB Assembly
Rigid-Flex PCB Assembly
Rigid-Flex PCB Assembly

Medical Device Rigid-Flex PCB Assembly

Name: Medical Device Rigid-Flex PCB Assembly

BGA mounting range: 0.18mm-0.4mm

Minimum placement material package: 01005

Minimum line width/spacing: 3mil/3mil

BGA pitch: 0.25mm

Minimum diameter of finished product: 0.1mm

Maximum size: 610mmX1200mm

Thickness: 0.3-3.5mm

Production equipment: 1 MYDATA solder paste jet printer, 1 solder paste detector, 2 MYDATA placement machines, 3 YAMAHA placement machines, 3 reflow soldering machines, and 1 wave soldering machine

Product Details Data Sheet

      Due to their high versatility, flex and rigid-flex PCBs have been widely integrated into many applications in the medical industry. Since rigid-flex PCBs eliminate the need for connectors, they reduce cost and the amount of installation space required. Their ability to fold into tight spaces makes them useful for medical devices and equipment. As innovations in medical technology continue to reduce the size and weight of devices - especially those that are wearable or portable - rigid-flex PCBs will continue to be sought after throughout the medical industry.


Some of the more common medical devices that require flex and rigid-flex PCBs include:

 Defibrillators: These devices restore a normal heartbeat by delivering an electrical shock to the heart tissue. There are different types of defibrillators, including implantable defibrillators, wearable defibrillators, automated external defibrillators (AEDs), and manually controlled external defibrillators commonly used in medical facilities. In all types of defibrillators, the PCB controls the electronics that allow these devices to function.

 Drug Delivery System: The drug delivery system provides controlled release of the drug. There are many types of equipment used for these purposes. One of the most common examples is an infusion pump, which injects drugs such as insulin or analgesics into a patient. In all systems, the PCB ensures accuracy and reliability.

Handheld Devices: Many medical devices are hand-held instruments, cameras or tools, and operator comfort during use is paramount. Flex and rigid-flex PCBs allow electronic devices to fit into the space available in these devices. Another benefit of rigid-flex technology is its resistance to degradation during autoclaving of medical devices.

 Handheld Monitors: Portable medical monitors can reliably monitor vital signs such as blood pressure, pulse oximetry, and body temperature. Flex and rigid-flex PCBs facilitate reliable device functionality and help reduce size and improve portability in recent designs.

 Medical Imaging Equipment: Medical imaging equipment is essential for diagnosing and treating patients with internal medical problems. Devices such as MRIs, X-rays, pill cameras, and CT scanners all rely on PCBs to operate.

 Pacemaker: A pacemaker regulates the rhythm of the heartbeat by sending out electrical pulses. Some need to run continuously, while others only run periodically in a more responsive fashion. In all cases, the PCB is essential for device operation.


We provide Medical Device Rigid-Flex PCB Assembly Rigid-Flex PCB Assembly services. Kingford is your one-stop rigid-flex circuit board assembly company.


4

Name: Medical Device Rigid-Flex PCB Assembly

BGA mounting range: 0.18mm-0.4mm

Minimum placement material package: 01005

Minimum line width/spacing: 3mil/3mil

BGA pitch: 0.25mm

Minimum diameter of finished product: 0.1mm

Maximum size: 610mmX1200mm

Thickness: 0.3-3.5mm

Production equipment: 1 MYDATA solder paste jet printer, 1 solder paste detector, 2 MYDATA placement machines, 3 YAMAHA placement machines, 3 reflow soldering machines, and 1 wave soldering machine

Just upload Gerber files, BOM files and design files, and the KINGFORD team will provide a complete quotation within 24h.
